Dirty Side: The dirty side of the QuickDraw features inside/outside (I/O) threads. The outside set of threads is only compatible with QuickDraw reservoirs.™ The inside set of threads is compatible with all common 28mm-thread plastic water bottles (like smartwater®), and narrow-mouth Platy bottles including the SoftBottle™, the Platy® 2L, PlatyPreserve™ and the Platy® Water Tank.

Clean Side: The QuickDraw’s ConnectCap threads directly to all common 28mm-thread plastic water bottles (like smartwater®), and narrow-mouth Platy bottles including the SoftBottle™, the Platy® 2L, PlatyPreserve™, the Platy® Water Tank, and the Hoser™ Reservoir.

The QuickDraw 2L and 3L Gravity models have a hose with a quick connector fitted on the end that clicks into any hydration reservoir with a quick disconnect, like the Big Zip™ Evo. Hydration reservoirs without a quick disconnect pair with the ConnectCap by removing the reservoir’s bite valve and pushing its hose onto the ConnectCap’s hose attachment point.

The QuickDraw 3L Gravity’s Bottle Adapter threads directly to common wide-mouth bottles like Nalgene®, Hydro Flask® and Yeti®. It also press-fits to narrow-mouth bottles like all common 28mm-thread plastic water bottles (such as smartwater®), and narrow-mouth Platy bottles including the SoftBottle™, the Platy® 2L, PlatyPreserve™, the Platy® Water Tank, and the Hoser™ Reservoir.

While both cleaning methods clean your filter and can easily be performed in the field or at home, they are intended to complement each other and allow you to keep your QuickDraw free of debris and flowing fast.

Shake-to-Clean: Is the quicker cleaning method and can be easily done every time you filter. It works by agitating and dislodging particulates attached to the hollow fibers, particularly at the opening on the dirty side of the filter.

Backflush: Backflushing is more time consuming and the more thorough way to clean your QuickDraw. It works by passing clean water through the length of your QuickDraw—in the clean side and out the dirty side—thereby rinsing and removing particulates stuck to the hollow fibers along the length of the bundle.

That often depends on the clarity/quality of water being filtered. However proactive cleaning will keep your filter flowing faster for longer. Consider the following proactive cleaning routine:

• Quickly perform a shake-to-clean before you filter each time you fill up.
• Backflush the filter after every 10L of water you filter through it.

Use your best judgement and adjust the routine as needed depending on frequency of use and quality of water.

Tea-colored water typically has a high concentration of decaying vegetation adjacent to, or in, a water source, resulting in a variety of organic acids. These acids, and the accompanying water conditions, are very hard on ALL types of water filters. Get your water elsewhere if you can.

However, if no alternatives exist, we recommend backflushing/cleaning your filter more frequently, even after each use. This will help minimize the clogging of the filter.

If your filter is new or has been sitting in storage for some time, you likely need to rewet the fibers. If you have been actively using your filter, then clogged particulates are the likely culprit. Click here for a troubleshooting FAQ.

An air purge can appear as a large mass of smaller, foamy bubbles, similar to a jacuzzi or rapidly boiling water, versus a localized steady stream of distinct bubbles from one or several specific spots on the filter that indicates damage. Click here for images of each scenario and more information.

Many replacement parts can be purchased directly from us online on our Accessories page or from one of our retailers. If you cannot find what you’re looking for, our customer support team can assist you:
